| 压缩标准支持 |
|---|
| 视频 | MPEG-2 Simple, Main, and 422P Profile up to High Level |
|---|
| MPEG-4 AVC/H.264 Baseline, Main, and High Profile，Up to Level 4.2 HD |
| 音频 | MPEG-1 layer 2 |
|---|
| MPEG-2 layer 3 (mp3) |
| MPEG2/MPEG-4, AAC-LC, AAC-HE |
| Dolby Digital E, AC-3 and pass through |
|
| 配置选择 |
|---|
| 格式转换 | PAL/NTSC to NTSC/PAL |
|---|
| 50i/25p to/from 60i/30p |
| 50p to/from 60p |
| 音频转码 | 全解码/全再编码模式 |
|---|
| 码率控制：CBR, VBR, Capped VBR |
| 输入/输出比特流格式：RTP/UDP/IP |
| 输入-输出接口：IP – 双千兆以太网口 |
| 配置和管理：嵌入式web服务器接口，SNMP控制 |
|
| 分辨率和帧速率 |
|---|
| SD转码 | HD转码 |
|---|
| 625 lines (PAL), 50 Hz | 720x576 @ 25 Hz 704x576 @ 25 Hz 544x576 @ 25 Hz 528x576 @ 25 Hz 480x576 @ 25 Hz 352x576 @ 25 Hz | 720p : 1280x720 @ 50 Hz 960x720 @ 50 Hz 1080i: 1920x1080 @ 25 Hz 1440x1080 @ 25 Hz 1280x1080 @ 25 Hz |
|---|
| 525 lines (NTSC), 60 Hz | 720x480 @ 29.97 Hz 704x480 @ 29.97 Hz 544x480 @ 29.97 Hz 528x480 @ 29.97 Hz 480x480 @ 29.97 Hz 352x480 @ 29.97 Hz | 720p : 1280x720 @ 59.94 Hz 960x720 @ 59.94 Hz 1080i: 1920x1080 @ 29.97 Hz 1440x1080 @ 29.97 Hz 1280x1080 @ 29.97 Hz 1080P: 1920x1080 @ 59.94 Hz |
|---|
|
